Ducted and Split System Air Conditioning Solutions in Tarragindi

Precision Electrical & Air has successfully executed the installation of dual air conditioning units at a residential property located in Tarragindi. This project involved the provision and installation of a Daikin ducted system on the upper level, along with a Daikin high-wall split system installed in the downstairs living room.

Comprehensive Installation of the Daikin FDYAN160AV1 16.0kW Ducted Air Conditioning System

Precision Electrical & Air undertook a thorough installation of the Daikin FDYAN160AV1 16.0kW ducted air conditioning system. The indoor unit was strategically positioned within the ceiling space above the void, while the outdoor condenser was securely mounted on the front balcony wall, using rubber feet to enhance stability. All connections between the indoor and outdoor units were carefully concealed within ductwork as they exited the ceiling space.

To ensure efficient water drainage, two drainage systems were installed from the indoor unit and safety tray, directing water to the external gutter. The installation included meticulous placement of ducting, branch takeoffs, zone motors, and air plenums throughout the ceiling space, enabling seamless integration with the indoor unit. a return air grille was installed in the upstairs hallway to optimise the system’s airflow.

A dedicated electrical sub-circuit was created, running from the switchboard to the outdoor unit. This circuit features an NHP isolation switch conveniently located next to the condenser. In the upstairs hallway, a MyZone Multipoint touchpad zone controller was installed, allowing for intuitive temperature management linked directly to the zone motors.

Professional Installation of the Daikin FTXV80W 8.0kW High-Wall Split System Air Conditioning

In the downstairs living room, the Daikin FTXV80W 8.0kW high-wall reverse cycle split system was installed with precision. New ducting, interconnect cables, and copper pair coils were added to link the indoor and outdoor units. The outdoor condenser was mounted on rubber feet to ensure stability during operation.

A dedicated electrical circuit was established from the switchboard to the outdoor condenser, which included an NHP isolation switch for enhanced safety. An Aspen Silent+ Mini condensation pump was installed beneath the indoor unit and connected to the nearest stormwater downpipe, facilitating efficient drainage. Upon completion, the system underwent extensive commissioning to ensure optimal performance.

Enhance Your Comfort with Advanced Zoned Air Conditioning Solutions

With these installations, the property now benefits from zoned ducted heating and cooling on the upper level, complemented by a dedicated high-wall unit in the downstairs living area. Both Daikin systems were supplied and installed in strict accordance with manufacturer specifications, ensuring all electrical circuits and drainage systems were properly established.

For professional ducted or split system air conditioning installation services in Tarragindi and the surrounding suburbs of Brisbane Southside, reach out to Precision Electrical & Air at 0423 163 359.
